Hot Air Oven

Hot Air Oven
Hot Air Oven
Send Inquiry
Product Code : KLM-10021
Product Description

Hot Air Oven

  • Bench top Hot Air Oven is suitable for drying, melting and sterilization in industrial and mining field, Laboratories and Scientific Research institute.
  • Precise Microprocessor PID Controller.
  • Temperature Range from 10 degree to 250 degree Celsius.
  • Reliable and Accurate Temperature Controller.
  • Double silicon glass door.
  • Optional RS 232 Communication interface.
  • Natural convection heating system.
  • Stainless steel door Mounted control panel digital temperature display rapid heat up time. inner chamber
  • Self diagnostic facility adjustable over temperature, safety thermostat corrosion resistance, easy to clean.
  • Stainless steel interior with powder coated exterior circulation fan.
  • Exterior remains at safety temperature (not overheated).
  • Quick, easy temperature setting Fast temperature recovery time.
  • Indicator lights to show which thermostat is controlling oven temperature.
  • 2 adjustable shelf heights oven temperature can be monitored.
  • Door opens minimum 180 degree and features grabber-type latch.
  • Microprocessor temperature control: 10 degree to 250 degree Celsius.
  • Touch screen continuous display.
  • Exhaust/Ventilation: adjustable ventilation flap located at the back of the machine.
  • Maximum air exchange per hour never exceeds: 25 temperature.
  • Audio/Visual alarm and over temperature protection.
  • The Monitor/controller shall automatically shutoff the heater if the unit exceeds the set temperature open door alarm.
  • Complied to IEC-60601 CE Certificate.
Microprocessor PID controller:

Provide precise temperature control from 10 degree to 250 degree Celsius, timer audio/visual alarm and over temperature protection.

Safety and convenience:

Quick easy temperature setting fast temperature recovery time and current  protection capability ensure user safety.

Silent fan motor:

Automatic defrost function to achieve excellent temperature uniformity and quiet operation.

Exhaust/ Ventilation adjustment:

Adjustable ventilation flap located at the back of the machine.

Back light LCD:

Displays current value and set value simultaneously.


Self Gnostic facility adjustable over temperature, safety thermostat corrosion resistant, easy to clean.

  • Oven Dimensions - 600 x 600 x 600 mm
  • Capacity - 200 Liter
  • Internal Material - Stainless steel
  • External material - Powder coated steel
  • Door open - Minimum 180 degree Celsius
  • Microprocessor temperature control - 10 degree  to 250 degree Celsius
  • Voltage - 220 V/ 50hz
  • Power - 1500W
  • Recovery time (at 200 degree Celsius) - Approx 5 mins.
  • Temperature Range - </= 250 degree Celsius
  • Temperature Sensor type - PT 100
  • Temperature setting increments - 1 degree Celsius
  • Time setting - 0-999min/0-99.9 hours
  • Max. Load per shelf - Approx. 15kg
  • Shelves - 2 adjustable Chrome plated grid standard
  • Resolution - 0.1 degree Celsius
  • Uniformity - +/- 2 degree Celsius
  • Temperature Fluctuations - +/- 1 degree Celsius
  • Alarm - Audio/Visual alarm type
